Single crystal substrates are fundamental materials for semiconductor and electronic devices due to their unique physical and electrical properties.
These include:
- Monocrystalline structure: Give uniform crystal orientation with no grain boundaries
- High electron mobility: Allows faster signal processing and device operation
- High mechanical strength: Less likely to deform or fracture
- Enhanced thermal conductivity: Dissipate heat efficiently
- Optical Transparency: In materials including sapphire and silicon carbide making them suitable for use in optical devices and sensors
- Uniform doping characteristics
They serve as the foundation upon which electronic circuits are built, enabling the development of high-performance devices with enhanced capabilities. Examples of applications are:
- Integrated circuits
- Power electronics
- Optical devices
- Sensors and detectors
- High-frequency devices
PI-KEM, in partnership with Surfacenet and MTI Corporation and other suppliers, offer a wide range of single crystals and substrates, both standard and custom grown
Order Your Single Crystal Substrates with PI-KEM
PI-KEM supplies a wide range of high-quality single crystal substrates, essential for the development of next-generation electronic, optical, and energy devices. We offer standard and custom-grown substrates in a variety of materials, including sapphire, silicon, oxides, titanates, niobates, and more.
Whether you need monocrystalline wafers, boules, tiles, prisms, or optical components, our substrates are manufactured to precise specifications with controlled orientation, purity, and surface finish. Our technical team can guide you in selecting the right material, size, orientation, and finish for your application, ensuring optimal performance for integrated circuits, sensors, optical devices, power electronics, and high-frequency devices.
Ready to order your single crystal substrates?
📞 Call our technical team on 01827 259250
📧 Email sales@pi-kem.co.uk
